4K HDMI 2.0 Splitter

The 1x2 HDMI Splitter uses a single HDMI source,accessing to multiple HDMI sinks.
It allows one HDMI device to be split easily to 2 HDMI compatible monitors or projectors. In addition，
it can be placed at the end of a long HDMI cable to regenerate the HDMI signal.
The resolution of this hdmi splitter can be up to 3840X2160/60Hz.

This product can support EDID management function, comes with eight kinds of EDID mode,
 the users can choose according to their own needs. In addition, it is with built-in IR extension function,
it can work with our hdmi 2.0 repeater which has IR-RX to receive the IR command to control the source.

Features:

1. Support HDMI 2.0 ,HDCP2.2
2. Support 3D video format
3. Support high resolution up to 3840X2160/60HZ
4. Support the max baud rate of 6G and TMDS clock can be up to 600 MHz
5. Support  8/10/12 bit deep color
6. Support AWG26 HDMI standard cable:
    when the resolution is 1080p and below, input up to 8 meters,output to 8 meters.
    when the resolution is 4K, input up to 8 meters, output up to 8 meters.
7. Support single HDMI source，accessing to multiple HDMI sinks, the source can be DVD player, A/V receiver,
    set top box and etc.Built-in IR extension function.( it can work with our hdmi 2.0 repeater
    which has IR-RX to receive the IR command to remote control the   source)
8. Support serial port online upgrade
9. Support EDID management
10. 5V/2A power adapter

Order Information
